TB9300 Installatio
n and Operation Manual
Appendix E T
esting with the T
BA0STU Calibr
ation T
est Unit
131
© Tait Internationa
l Limited
April 2024
Appendix E T
esting with the TBA0STU
Calibration T
est Unit
The TBA0STU Calibration
T
est Unit (C
TU) can be used with TB9300 base
stations with hardware version 1.01 (o
r later) and firmware
version 2.60 (or
later). T
e
sting can be done for the balanced audio line, RSSI, TX Key
, and
RX gate.
CTU Connections and Controls
130
132
