TM8100/TM8200 Service Manual General Information 107
© Tait Electronics Limited June 2006
Service Kit The service kit contains all the items needed for connecting the radio to the
test equipment. The setting up of the equipment is described in “Test
Equipment Setup” on page 111. The service kit also includes a product
support CD and a folder with the necessary service documentation,
including this manual. The CD contains the programming application,
calibration application, and soft-copies of the service and related
documentation. The contents of the service kit are listed in Table 4.2. Note
that the TMAA20-04 cable listed is required only if the test PC is to be
connected directly to the radio for programming purposes.
Note The characters xx below stand for the issue number of the manual.
Only the latest issue of each manual will normally be available for
ordering.
Table 4.2 Contents of service kit (TMAA21-00)
Product code Item
TMAA20-02 Cable (RJ45 socket to DB9 socket)
TMAA20-03 Cable (25W power connector to banana plugs plus speaker connector)
TMAA20-04 Cable (RJ12 socket to RJ45 plug)
TMAA21-01 Cable (DB15 socket to RJ45 plug plus speaker connector)
TMAA23-02 Cable (50W/40W power connector to banana plugs plus speaker connector)
T2000-A19 Cable (DB9 socket to RJ12 plug)
TOPA-SV-024 Test unit
MMA-00005-xx Service manual
MMA-00037-xx PCB information
TMAA20-01 Product support CD
406-00046-xx Programming CD
