Technicolor CGA4131 User Manual

3/6/2018 Proprietary and Confidential - Technicolor 52
User can select Channel Width manually from any of these three options:
1. 20 MHz
2. 20/40 MHz
3. 20/40/80 MHz
Note:
1. Option 2.20/40 MHz is possible in 2.4GHz or 5GHz wireless interfaces but only when
Network Mode includes 802.11n or 802.11ac.This is not possible with the selection
of only 802.11 b/ 802.11g /802.11a mode.
2. Option 3.20/40/80 MHz is only possible with 5GHz and Network Mode includes
802.11 ac.
Channel:
User can select either select any one channel accordingly from the available drop down list
or can select the gateway to be in AUTO. The recommended setting is to leave the gateway
channel selection in AUTO mode so that the CGA4131 can continuously scan and use
channels with less interference.
MAC Address:
The wireless MAC address is displayed in this field.
Scan Nearby AP:
The Scan button provides a mechanism for the AP to scan neighboring APs and provides
various statistics on neighbors.
7.1.2 SNMP provisioning for Radio
S.
No.
MIBs
Description
1
rdkbRgdot11nExtMode
rdkbRgdot11nExtMode selects the
Network Mode
2
rdkbRgdot11nExtBandWidth
rdkbRgdot11nExtBandWidthselects
the channel width for 802.11n operation.
3
rdkbRgDot11ExtCurrentChannel
rdkbRgDot11ExtCurrentChannelselects
the channel. The list of the available
channels depends on the radio capabilities
and country code.
4
rdkbRgdot11nExtSideBand
rdkbRgdot11nExtSideBand- This is for N
cards only.
5
rdkbRgDot11BssSsid
rdkbRgDot11BssSsidsets the Network
Name (SSID).
6
rdkbRgDot11BssClosedNetwork
rdkbRgDot11BssClosedNetworkcontrols
whether the Network Name (SSID) will be
hidden in the beacon frames or not.
