Unit Description
29
Opening the Front Doors
Pull the door latch handle to open the door and access the
engine compartment.
Opening the Secondary Door Latch
These units are also equipped with a secondary door latch. A
secondary door latch nameplate is located below the front
doors. After opening the door latch, reach between the front
doors and lift the spring latch over the spring catch while
opening the door.
1. Door Latch
2. Secondary Door Latch Nameplate
Figure 9: Door Latch Location
1
2
1. Spring Latch
2. Spring Catch
Figure 10: Opening Secondary Door Latch
1
2
Unit Description
29
Opening the Front Doors
Pull the door latch handle to open the door and access the
engine compartment.
Opening the Secondary Door Latch
These units are also equipped with a secondary door latch. A
secondary door latch nameplate is located below the front
doors. After opening the door latch, reach between the front
doors and lift the spring latch over the spring catch while
opening the door.
1. Door Latch
2. Secondary Door Latch Nameplate
Figure 9: Door Latch Location
1
2
1. Spring Latch
2. Spring Catch
Figure 10: Opening Secondary Door Latch
1
2
