Specifications
95
Belt Tension
Belt Tension No. on TK Gauge 204-427
Alternator Belt 61
Lower Fan Belt (Engine to Idler) 67
Upper Fan Belt (Fan to Idler) 74
NOTE: These are the field reset settings. Because it is sometimes difficult to use the TK Gauge 204-427 in the
field, adjust each belt to allow 1/2 inch (13mm) deflection at the center of the longest span.
Electrical Control System
Voltage 12.5 Vdc
Battery One, Group C31, 12 volt, (950 CCA recommended for operation
below -15 F [-26 C])
Battery Charging Alternator 12 V, 37 Amp (brush type)
Voltage Regulator Setting 13.8 to 14.2 Vdc at 77 F (25 C)
Fuses 2 to 40 Amp (see “Fuses” on page 33)
Specifications
95
Belt Tension
Belt Tension No. on TK Gauge 204-427
Alternator Belt 61
Lower Fan Belt (Engine to Idler) 67
Upper Fan Belt (Fan to Idler) 74
NOTE: These are the field reset settings. Because it is sometimes difficult to use the TK Gauge 204-427 in the
field, adjust each belt to allow 1/2 inch (13mm) deflection at the center of the longest span.
Electrical Control System
Voltage 12.5 Vdc
Battery One, Group C31, 12 volt, (950 CCA recommended for operation
below -15 F [-26 C])
Battery Charging Alternator 12 V, 37 Amp (brush type)
Voltage Regulator Setting 13.8 to 14.2 Vdc at 77 F (25 C)
Fuses 2 to 40 Amp (see “Fuses” on page 33)
