Toshiba B-EV4 Series User Manual

- 169 -
6.3.29 VERSION INFORMATION ACQUIRE COMMAND [ESC] WV
Function Sends information such as the program version of the printer.
Format [ESC] WV [LF] [NUL]
Explanation (1) The format of the program version data (total 27 bytes of data) to be returned to
the host is as follows.
SOH 01H
STX 02H
“0” 30H
“4” 34H
“A” 41H
“P” 50H
Creation date “R” 52H
“2” 32H
“0” 30H
“0” 30H
“3” 33H
“B” 42H
“-“ 2DH
“E” 45H
Model “V” 56H
“4” 34H
“D” 44H
SP 20H
“V” 56H
“1” 31H
Version “.” 2EH
“0” 30H
“A” 41H
ETX 03H
EOT 04H
CR 0DH
LF 0AH
(2) This command is one of the types of commands that is processed as it is received.
Processing takes place starting from the ones received first. Until the process of
the command previously sent is completed, the next command is not processed.
Therefore, if the printer is not in the idle state when this command is sent, the
program version data may not be returned immediately.
Notes (1) This command is effective only for the serial interface (RS-232C).
This command is not supported for a parallel interface (Centronics), since
transmission cannot be performed in the parallel interface.
Creation date of program:
9 bytes of data indicated in order of Day-
Month-Year
Program version:
5 bytes of data: Vx.xx
Revision
Version
Model:
7 bytes of ASCII code indicating model

Toshiba B-EV4 Series Specifications

General

Print Method	Direct Thermal / Thermal Transfer
Power Supply	AC 100-240V, 50/60 Hz
Operating Temperature	5°C to 40°C
Print Resolution	203 dpi, 300 dpi
Max Print Speed	Up to 127 mm/sec (5 ips) (203 dpi) / Up to 101.6 mm/sec (4 ips) (300 dpi)
Interface	USB, Serial
Optional Interfaces	Wireless LAN
Weight	2.4 kg
Barcodes	Code 39, Code 128
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Media Width	25.4 mm to 112 mm
Media Thickness	0.06 mm to 0.19 mm
Media Roll Diameter	Max. 127 mm
Ribbon Width	40 mm to 110 mm
Ribbon Length	300 m
Operating Humidity	25% to 85% non-condensing
