- 87 -
e In the case of bar codes other than JAN, EAN, and UPC
(Example) CODE39
(Example) UCC/EAN128
(10) Start/Stop Code
y This parameter is valid only when the type of bar code is CODE39 and NW7.
y Where the parameter is designated, the program will not check if the transmit print data
is with a start code and stop code.
y When the parameter is omitted in the case of CODE39 and NW7, a start/stop code will
be attached. The code to be added is “*” in the case of CODE39, and “a” in the case of
NW7.
y For details, refer to “Auto Attachment of Start/Stop Code” to be discussed later in this
specification.
(11) Increment/decrement
Printing is performed while the data is incremented or decremented every time a label is
issued. Where the data row exceeds the maximum number of digits (40), the data row
will not be drawn.
When CODE128 (without auto code selection) is used, the number of the start code
(code A, code B, and code C) digits is regarded as 2.
Initial value 0000 0000 0000 0000 999999
INC/DEC +10 +10 +10 +10 +1
Zero suppression
Not
designated
5 3 0 3
1st label 0000 0000 000 0000 999999
2nd label 0010 0010 010 0010 000
3rd label 0020 0020 020 0020 001
4th label 0030 0030 030 0030 002
5th label 0040 0040 040 0040 003
