- 24 -
6.3.2 POSITION FINE ADJUST COMMAND [ESC] AX
Function c Adjusts the feed value so that the label will be shifted forward or backward from the
automatically set first print start position.
d Adjusts the cut position so that the label will be cut at a position shifted forward or
backward from the automatically set cut position, or adjusts the strip position so that
the label will be shifted forward or backward from the automatically set strip position.
e Adjusts the value for feeding the label back to the home position after cutting, or
adjusts the value for feeding the label back to the home position after stripping.
Format [ESC] AX; abbb, cddd, eff [LF] [NUL]
Term a: Indicates the direction, forward or backward, in which a fine adjustment is to
be made.
+: Backward
-: Forward
bbb: Feed value to be finely adjusted.
000 to 500 (in 0.1 mm units)
c: Indicates the direction, forward or backward, in which a cut position
(or strip position) fine adjustment is to be made.
+: Backward
-: Forward
If cutter and strip module is not installed, this value is ignored.
ddd: Amount for finely adjusting the cut position (or strip position).
000 to 180 (in 0.1 mm units)
If cutter and strip module is not installed, this value is ignored.
e: Indicates whether the back feed is to be increased or decreased.
+: Increase
-: Decrease
ff: Amount for finely adjusting the back feed.
00 to 99 (in 0.1 mm units)
To Next Page
