Tests and Diagnostics
3-22 [CONFIDENTIAL] Qosmio F60 Series Maintenance Manual (960-796)
3.7 Memory Test
To execute the Memory Test, select 2 from the DIAGNOSTIC TEST MENU, press Enter
and follow the directions on the screen. Move the highlight bar to the subtest you want to
execute and press Enter.
Subtest 01 Conventional memory
This subtest writes a constant data to conventional memory (0 to 640 KB),
then reads the new data and compares the result with the original data.
Subtest 02 Protected Mode
NOTE: The CONFIG.SYS file must be configured without expanded memory manager
programs such as EMM386.EXE, EMM386.SYS or QEMM386.SYS. Also, the
HIMEM.SYS must be deleted from the CONFIG.SYS file.
This subtest writes constant data and address data (from 1MB to maximum
MB), and reads the new data and compares the result with the original data.
Subtest 03 Cache memory (on/off)
To test the cache memory, a pass-through write-read comparison of ‘5Ah’
data is run repeatedly to the test area (‘7000’: ‘Program’ size to ‘7000’:
‘7FFF’ (32 KB)) to check the hit-miss ratio (on/off status) for CPU cache
memory. One test takes 3 seconds.
Number of misses Number of hits OK
Number of misses Number of hits Fail
Subtest 04 Stress
Write/Read buffer (1 size = B30h) is prepared in the conventional memory.
The data is made in the Write Buffer, the data in Write Buffer is written in the
area of address of 1MB or after. The data is red in the Read Buffer and data is
compared in area up to the maximum size.
Data: FFh, FFh, FFh, FFh, FFh, 00h, 00h, 00h, 00h,
FFh, FFh, FFh, 00h, FFh, 00h, 00h, FFh, 00h,
00h, FFh, FFh, FFh, FFh, 00h, 00h, 00h, AAh
