Toshiba Qosmio F60 Series Maintenance Manual

エラー ! スタイルが定義されていません。 Replacement Procedures エラー !
ス
4.17 Wireless LAN card
Removing the wireless LAN card
To remove the wireless LAN card, follow the steps below and refer to Figure 4-26.
1. Disconnect the wireless LAN antenna cables from the connectors on the wireless
LAN card.
2. Remove the following screws securing the wireless LAN card.
 M2.04B BIND screw 2
3. Disconnect the wireless LAN card from the connector CN2600 on the system board.
M2.0x4B BIND
CN2600
Wireless LAN antenna cable
Wireless LAN card
Figure 4-26 Removing the wireless LAN card
4-44 [CONFIDENTIAL] QOSMIO F60 Maintenance Manual (960-796)
