Toshiba Qosmio F60 Series Maintenance Manual

Appendices Appendix C Pin Assignments
C-8 [CONFIDENTIAL] Qosmio F60 Serise Maintenance Manual (960-796)
C.5 CN1930 eSATA/USB interface connector (11-pin)
Table C- 5 eSATA/USB interface connector (20-pin)
Pin No. Signal Name Pin No. Signal Name
P1 USB0PS-E5V P2 ZUSBP4C-E3N
P3 ZUSBP4C-E3P P4 GND
P5 GND P6 ZSTTES-P1P
P7 ZSTTES-P1N P8 GND
P9 ZSTRES-P1N P10 ZSTRES-P1P
P11 GND
1T GND 2T GND
3T GND 4T GND
