Toshiba Qosmio F60 Series Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio F60 Series Maintenance Manual (960-796) [CONFIDENTIAL] C-17
C.21 CN9570 FELICA interface connector (6-pin) :Japanese model
Only
Table C- 21 FELICA interface connector (6-pin)
Pin No. Signal Name Pin No. Signal Name
1 Q9570-1 2 ZUSBP9-E3N
3
ZUSBP9-E3P
4
GND
5 NC 6
GND
1T GND 2T
GND
C.22 CN9332 RTCVCC interface connector (3-pin)
Table C- 22 RTCVCC interface connector (3-pin)
Pin No. Signal Name Pin No. Signal Name
1 RTC-R3V 2 NC
3 GND
1T GND 2T GND
C.23 CN5350 HDMI interface connector (19-pin)
Table C-23 HDMI interface connector (19-pin)
Pin No. Signal Name Pin No. Signal Name
1 ZHDT2-PYN 2 GND
3 ZHDT2-PYN 4
ZHDT1-PYP
5
GND
6
ZHDT1-PYN
7
ZHDT0-PYP
8
GND
9
ZHDT0-PYN
10
ZHDCK-PYP
11
GND
12
ZHDCK-PYN
13
CECIN-S3N
14
NC
15
CEC-S5V
16
CEC-S5V
17
GND
18
CEC-S5V
19
HPDETI-S3P
1T
GND
2T
GND
3T
GND
4T
GND
