Toshiba Qosmio F60 Series Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio F60 Series Maintenance Manual (960-796) [CONFIDENTIAL] C-9
C.6 CN2600 PCI-E Mini CARD interface connector (52-pin)
Table C- 6 PCI-E Mini CARD interface connector (52-pin)
Pin No. Signal Name Pin No. Signal Name
1 PEWAKE-E3N 2 WLAN-E3V
3 WCHDAT-P3P 4 GND
5 WCHCLK-P3P 6 1R5-P1V
7 WLXRQ-E3N 8 NC
9 GND 10 NC
11 XPEWL-P0N 12 NC
13 XPEWL-P0P 14 NC
15 GND 16 NC
17 NC 18 GND
19 NC 20 WLRFON-S3N
21 GND 22 PLTRS2-E3N
23 ZERMN1-P1N 24 WLAN-E3V
25 ZERMN1-P1P 26 MN1PRS-P3N
27 GND 28 1R5-P1V
29 GND 30 NC
31 ZETMN1-P1N 32 NC
33 ZETMN1-P1P 34 GND
35 GND 36 ZUSBP0-E3N
37 GND 38 ZUSBP0-E3P
39 WLAN-E3V 40 GND
41 WLAN-E3V 42 WMLED-E3P
43 GND 44 NC
45 NC 46 NC
47 NC 48 1R5-P1V
49 NC 50 GND
51 NC 52 WLAN-E3V
1T
GND
2T
GND
