Toshiba Qosmio F60 Series Maintenance Manual

Appendices Appendix C Pin Assignments
C-12 [CONFIDENTIAL] Qosmio F60 Serise Maintenance Manual (960-796)
C.10 CN4612 USB interface connector (4-pin)
Table C- 10 USB interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1
USB2PS-E5V 2 ZUSBP5-E3N
3 ZUSBP5-E3P
4
GND
1T GND
2T
GND
3T GND
C.11 CN4613 USB interface connector (4-pin)
Table C- 11 USB interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1
USB1PS-E5V 2 ZUSBP1-E3N
3 ZUSBP1-E3P
4
GND
1T GND
2T
GND
C.12 CN4440 Bluetooth2 interface connector (10-pin)
Table C- 12 Bluetooth2 interface connector (10-pin)
Pin No. Signal Name Pin No. Signal Name
1 GND 2
GND
3 P3V 4 WCHDAT-P3P
5 BTRST-S3N 6 BTMDL-P3N
7 WCHCLK-P3P 8
ZUSBP8-E3N
9 ZUSBP8-E3P 10
1T GND
2T
GND
