Toshiba Qosmio F60 Series Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio F60 Series Maintenance Manual (960-796) [CONFIDENTIAL] C-7
C.3 CN1900 SATA HDD interface connector (20-pin)
Table C- 3 SATA HDD interface connector (20-pin)
ピン No. 信号名 ピン No. 信号名
1 GND 2 GND
3 GND 4 GND
5 GND 6 GND
7 GND 8 P5V
9 P5V 10 P5V
11 GND 12 GND
13 GND 14 GND
15 ZSATR0-P1P 16 ZSATR0-P1N
17 GND 18 ZSATT0-P1N
19 ZSATT0-P1P 20 GND
1T GND 2T GND
3T GND 4T GND
C.4 CN1950 SATA ODD interface connector (13-pin)
Table C- 4 SATA ODD interface connector (23-pin)
Pin No. Signal Name Pin No.
Signal Name
S1 GND S2 ZSATT1-P1P
S3 ZSATT1-P1N S4 GND
S5 ZSATR1-P1N S6 ZSATR1-P1P
S7 GND
P1
NC（S3V）
P2 ODD-P5V
P3 ODD-P5V P4 NC
P5 GND P6 GND
