QOSMIO F60 Maintenance Manual (960-796) [CONFIDENTIAL] 4-23
4.8 Cover assembly
Removing the Cover assembly
To remove the cover assembly, follow the steps below and refer to Figure 4-11 to 4-13.
1. Close the display and turn over the computer.
2. Disconnect the TV tuner antenna cable and speaker harness from the connectors
on the TV tuner and CN6150 on the system board. (When replacing the TV tuner
antenna cable, speaker or system board.)
3. Remove the following screws securing the cover assembly.
 M2.56B FLAT HEAD screw 12 (Described as “6” in the figure)
 M2.510B FLAT HEAD screw 6 (Described as “10” in the figure)
 M2.516B FLAT HEAD screw 3 (Described as “16” in the figure)
