Appendix C Pin Assignments Appendices
Qosmio F60 Series Maintenance Manual (960-796) [CONFIDENTIAL] C-1
Appendix C Pin Assignments
System board (FLESY*)
C.1 CN1400 Memory A connector(200-pin)
Table C- 1 Memory A connector (200-pin) (1/3)
Pin No. Signal Name Pin No. Signal Name
1 MR0R75-B0V 2 GND
3 GND 4 ADQ00-B1P
5 ADQ05-B1P 6 ADQ04-B1P
7 ADQ01-B1P 8 GND
9 GND 10 ADQS0-B1N
11 ADM0-B1P 12 ADQS0-B1P
13 GND 14 GND
15 ADQ07-B1P 16 ADQ02-B1P
17 ADQ06-B1P 18 ADQ03-B1P
19 GND 20 GND
21 ADQ09-B1P 22 ADQ12-B1P
23 ADQ08-B1P 24 ADQ13-B1P
25 GND 26 GND
27 ADQS1-B1N 28 ADM1-B1P
29
ADQS1-B1P
30
ASMRST-B1
31 GND 32 GND
33 ADQ10-B1P 34 ADQ14-B1P
35 ADQ15-B1P 36 ADQ11-B1P
37 GND 38 GND
39 ADQ20-B1P 40 ADQ21-B1P
41 ADQ16-B1P 42 ADQ17-B1P
43 GND 44 GND
45 ADQS2-B1N 46 ADM2-B1P
47 ADQS2-B1P 48 GND
49 GND 50 ADQ22-B1P
51 ADQ18-B1P 52 ADQ23-B1P
53 ADQ19-B1P 54 GND
55 GND 56 ADQ29-B1P
57 ADQ24-B1P 58 ADQ28-B1P
59 ADQ25-B1P 60 GND
