Appendices Appendix C Pin Assignments

C-10 [CONFIDENTIAL] Qosmio F60 Serise Maintenance Manual (960-796)

C.7 CN2610 PCI-E Mini(TV) CARD interface connector (52-pin)

Table C- 7 PCI-E Mini(TV) CARD interface connector (52-pin)

Pin No. Signal Name Pin No. Signal Name

1 NC 2 P3V

3 XBCCLK-P3P 4 GND

5 BCCDET-P3N 6 1R5-P1V

7 NC 8 UIMPWR-E3V

9 GND 10 UIMDAT-E3P

11 NC 12 UIMCLK-E3P

13 NC 14 UIMRST-E3P

15 GND 16 BCIO-P5P

BCRST-P3N

18 IVDET-P3P

BCPWON-P3P

20 3GRFON-S3N

21 GND 22 PLTRS0-E3N

23 NC 24 P3V

25 NC 26 GND

27 GND 28 1R5-P1V

29 GND 30 ZUSB12-E3P

31 NC 32 ZUSB12-E3N

33 NC 34 GND

35 GND 36 ZUSB10-E3N

37 GND 38 ZUSB10-E3P

39 P3V 40 MN2PRS-P3N

41 P3V 42 NC(GND)

43 GND 44 CPLGP1-P3P

45 NC 46 TMPTU1-SXP

TMPTU2-SXP

48 1R5-P1V

49 NC 50 (TMPTUN-GND)

51 NC 52 P3V

GND
