Appendix B Boar
d Layout
Appendices
B.5
T
ouch Pad En-SW board (FLETP*)View
(front)
(back)
Figure B-5 T
ouch Pad En-SW board (FLETP*) layout (front
/back
)
T
able B-5 T
ouch Pad En-SW board (FLETP*) connector (
back
)
Number Name
CN3331
System board interface connector
Qosmio F60 Serie Maintenance Manual
(960-796)
[CONFIDENTIAL]
B-7
418
420
