4.28 TV tuner
Removing the TV tuner
CAUTION: When replacing the TV tuner with a new one, refer to the chapter 3”TV
tuner maintenance” and create the key information from the system board to
the TV tuner.
When replacing the TV tuner and system board in the same time, refer to the
chapter 3”TV tuner maintenance” and prepare a new key.
To remove the TV tuner, follow the steps below and refer to Figure 4-44.
1. Remove the following screws and disconnect the TV tuner from the connector
CN2610 on the system board.
 M2.04B BIND screw 2
M2.0x4B BIND
TV tuner
CN2610
Figure 4-44 Removing the TV tuner
QOSMIO F60 Maintenance Manual (960-796) [CONFIDENTIAL] 4-73
