Toshiba Qosmio F60 Series Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio F60 Series Maintenance Manual (960-796) [CONFIDENTIAL] C-21
USB/Sound board (FLEJK*)
C.31 CN6491 System board interface connector (22-pin)
Table C- 31 System board interface connector (22-pin)
Pin No. Signal Name Pin No. Signal Name
1 USB1PS-E5V 2 USB1PS-E5V
3
USB1PS-E5V
4
NC
5 GND 6
GND
7
ZUSBFR-E3N
8
ZUSBFR-E3P
9 GND 10
NC
11
GND
12
EMCINL-PXP
13
GND
14
EMCINR-PXP
15
EMICB-P2V L
16
DETCTA-P4N
17
IMICB-P2V
18
IMICIN-PXP
19
GND
20
HEADL-PXP
21
GND
22
HEADR-PXP
1T GND 2T GND
C.32 CN4640 USB interface connector (4-pin)
Table C- 32 USB interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1
USB1PS-E5V
2
ZUSBFR-E3N
3 ZUSBFR-E3P
4
GND
1T GND
2T
GND
3T GND
C.33 J6071 Microphone connector (6-pin)
Table C- 33 Microphone connector (6-pin)
Pin No. Signal Name Pin No. Signal Name
1 A-GND 2 EMCINL-PXP
3 EMCINR-PXP 4 A-GND
5 DETCTA-P4N 6 NC
