Toshiba Qosmio F60 Series Maintenance Manual

エラー ! スタイルが定義されていません。 Replacement Procedures エラー ! スタイルが定義されて
い
4.6 HDD
Removing the HDD
To remove the HDD, follow the steps below and refer to Figure 4-6 and 4-7.
CAUTION: Take care not to press on the top or bottom of a HDD. Pressure may cause
data loss or damage to the device.
1. Remove the following screw securing the HDD cover.
 M2.54B FLAT HEAD screw 1
2. Insert your finger into the slit and remove the HDD cover.
M2.5x4B FLAT HEAD
HDD cover
Slit
Figure 4-6 Removing the HDD cover
4-18 [CONFIDENTIAL] QOSMIO F60 Maintenance Manual (960-796)
