Toshiba Qosmio F60 Series Maintenance Manual

Appendices Appendix B Board Layout
B-2 [CONFIDENTIAL] Qosmio F60 Series Maintenance Manual (960-796)
Table B-1 System board (FLESY*) connectors and ICs (front)
Number Name
CN1900 SATA HDD interface connector
CN2600 PCI-E MINI CARD I/F connector
CN3490 It is debugging port for development only
CN3230 KB interface connector
CN4050 LAN interface connector
CN4440 Bluetooth2 interface connector
CN5300 LCD interface connector
CN9550 WebCam interface connector
CN9510 RGB interface connector
CN9332 RTCVCC interface connector
IS2621
SIM Card（BCAS, 3D card, other card）interface connector
CN9660 Touch Sensor interface connector
CN9570 FELICA interface connector (6-pin) :Japanese model Only
CN3390 FLEPW*(Power SW board) interface connector
CN4631 FLEJK*(USB/Sound board) interface connector
CN3240 F LETB*(Touch Pad SW board) interface connector
CN3241 FLETP*(Touch Pad En-SW board) interface connector
CN3242 FLELE*(LED board) interface connector
