4 Replacement Procedures Error! Style not defined. Error! Style not defined.
4.2 Battery
Removing the Battery Pack
Remove the battery pack according to the following procedures and Figure 4-1.
CAUTION: When handling the battery packs, use care not to short circuit the terminals. Do
not drop, hit, twist, or bend the battery packs. Do not scratch or break up their casing.
1. Turn the computer upside down so that the back is facing you.
2. Slide out the battery lock.
3. Slide the battery release latch and remove the battery pack from the computer.
Figure 4-1 Removing the battery pack
NOTE: Dispose of the used battery packs as required by local ordinances or regulations.
Qosmio X300 Maintenance Manual 4-8
