4 Replacement Procedures Error! Style not defined. Error! Style not defined.
4.3 HDD
Removing the HDD
CAUTION: Do not press on the top or bottom of the drive.
Applying such pressure can either corrupt the data in the
drive or damage the drive.
Remove the HDD (hard disk drive) according to the following procedures and Figures 4-2, 4-3.
1. Remove two M2.5x4 HDD cover screws that secure the HDD and then remove the HDD
cover.
Figure 4-2 Removing the HDD pack cover
Qosmio X300 Maintenance Manual 4-10
