Error! Style not defined. Error! Style not defined. 4 Replacement Procedures
Qosmio X300 Maintenance Manual 4-21
Installing the Wireless LAN card and UWB Card
Install the wireless LAN card and UWB card according to the following procedures and Figures
4-7, 4-8.
1. Insert the wireless LAN card into the connector an angle of 45 degrees.
2. Connect 2 or 3 antenna cables (depending on the model).
3. Press down on the wireless LAN card to secure it with two M2x4 screws.
4. Insert the UWB card into the connector an angle of 45 degrees.
5. Connect one antenna cable.
6. Press down on the UWB card to secure it with two M2x4 screws.
CAUTION: Do not touch the connectors on the wireless LAN card and in the computer with
your bare hands. Wireless LAN cards can fail if they are contaminated with sweat, natural
oils, etc. from your hands.
