4 Replacement Procedures Error! Style not defined. Error! Style not defined.
4.13 Speakers
Removing the Speakers
Remove the Speakers according to the following procedures and Figure 4-20.
1. Remove two M2.5x6 screws securing the left speaker.
2. Remove two M2.5x6 screws securing the right speaker.
3. Remove the speaker cable from the wire guide.
4. Remove the left and right speakers.
Figure
4-20 Removing the speakers
CAUTION: Use care to avoid that the speaker cable is not caught on the top cover of the
computer.
Qosmio X300 Maintenance Manual 4-36
