4.27 LCD Modules
NOTE: ICs are fragile. Use extreme care not to apply pressure to the ICs along the edges of
the LCD module.
NOTE: Dispose of used LCD panels (fluorescent (FL) tubes) as required by local ordinances
or regulations.
NOTE: The LCD/FL cable must be carefully peeled away before disconnecting it from the
module.
Removing the 17.1-inch LCD module
Remove the 17.1-inch LCD module according to the following procedures and Figures 4-41,
4-42.
1. Remove six M2.5x6 screws on the top of the LCD bracket.
2. Remove six M2x3 screws on two sides of the LCD (three on each side).
