Qosmio X300 Series Maintenance Manual [CONFIDENTIAL] F-1
F.
Appendix F Series Screw Torque List
Table F-1 Series Screw Torque List
SCREW P/N SCREW SPEC Q'ty LOCATION SCREW TORQUE
MA0000060G0 M2.0*3 6 LCD HINGE BRK ASSY L&R TO LCD PANEL 17w" 1.2~1.5Kgf-cm
MACK20040G0 M2.0*4 1 INVERTER TO HINGE WALL 1.5~2.0Kgf-cm
6 LCD HINGE L&R TO LCD COVER 2.5~3.0Kgf-cm
MA0000062G0 M2.5*6
6 LCD BEZEL TO COVER 2.5~3.0Kgf-cm
MMCK20080G0 M2.0*8 2 1ST HDD(H=16.6mm) CONNECTOR TO MB 1.5~2.0Kgf-cm
2 EXPRESS-CARD CONNECTOR TO MB 1.5~2.0Kgf-cm
2 2ND HDD(H=1.9mm) CONNECTOR TO MB 1.5~2.0Kgf-cm
2 ODD-CONN TO MB 1.5~2.0Kgf-cm
MACB20251G0 M2.0*6
2 BATTERY CONNECTOR TO MB 1.5~2.0Kgf-cm
2 EXPRESS CARD HOUSING TO MB 1.5~2.0Kgf-cm
2 WLAN CARD TO MB STANDOFF 2.0~2.5Kgf-cm
2 UWB CARD TO MB STANDOFF 2.0~2.5Kgf-cm
2 DRIVER CACHE TO MB STANDOFF 2.0~2.5Kgf-cm
2 TMA CARD TO TMA BRK 2.0~2.5Kgf-cm
MACK20040G0 M2.0*4
2 TMA BRK TO MB 2.0~2.5Kgf-cm
2
MDC CARD TO MB STANDOFF BTO
FM MODULE TO SADDLE R BTO
2.5~3.0Kgf-cm
MA0000061G0 M2.5*4
6
VGA BOARD SLI TO M/B
Single VGA board*4
2.5~3.0Kgf-cm
2 SPEAKER(R) TO LOG UP 2.5~3.0Kgf-cm
MA0000062G0 M2.5*6
2 SPEAKER(L) TO LOG UP 2.5~3.0Kgf-cm
1 POWER PCB TO LOG UP 2.5~3.0Kgf-cm
1 AUDIO PCB TO LOG UP 2.5~3.0Kgf-cm
MA0000061G0 M2.5*4
2 TP BUTTON PCB TO LOG UP 2.5~3.0Kgf-cm
MA0000061G0 M2.5*4 2 SADDLE L&R TO LOW 2.5~3.0Kgf-cm
MACB20251G0 M2.0*6 4
THERMAL FAN TO MB STANDOFF
VGA10G w/o TMA use MACB20251G0*2
VGA10G w TMA use MACB20251G0*2
VGA10H w/o TMA use MACB20251G0*4
VGA10H w TMA use MACB20251G0*4
2.0~2.5Kgf-cm
4 CPU-THERMAL-SINK TO CPU-PLATE 2.5~3.0Kgf-cm
3
VGA1 THERMAL SINK TO VGA-PLATE
NB9E USE AM01O000300 / NB9P USE
AM04I000600(black)
2.5~3.0Kgf-cm
AM01O000300
AM04I000600(black)
SPRING SCREW
3
VGA2 THERMAL SINK TO VGA-PLATE
NB9E USE AM01O000300 / NB9P USE
AM04I000600(black)
2.5~3.0Kgf-cm
MACK20040G0 M2.0*4 3 TMA THERMAL SINK TO TMA-PLATE 2.0~2.5Kgf-cm
1 KILL SWITCH BOARD TO LOW 2.5~3.0Kgf-cm
1 T/P LED BOARD TO LOW 2.5~3.0Kgf-cm
3 MB TO LOG LOW 2.5~3.0Kgf-cm
2 LOG LOW TO LOG UP (ODD AREA) 2.5~3.0Kgf-cm
4 KEYBOARD TO UP 2.5~3.0Kgf-cm
MA0000061G0 M2.5*4
2 HDD DOOR TO LOG LOW 2.5~3.0Kgf-cm
1 LOG LOW HINGE WALL TO LOW 2.5~3.0Kgf-cm
MA0000062G0 M2.5*6
4 LCD HINGE R&L TO SADDLE R&L 4.0~4.5Kgf-cm
