Qosmio X300 Maintenance Manual 4-12
Installing the HDD
Install the HDD according to the following procedures and Figures 4-2, 4-3.
CAUTION: To avoid damage, always hold the HDD only by its sides.
1. Place the HDD into the HDD chassis.
2. Secure the HDD and its chassis with four M3x3 screws.
CAUTION: To prevent the HDD bracket from being distorted when installing the HDD pack
into the computer, do not press the center of the HDD pack. Always hold the HDD pack by its
sides.
3. Install the HDD pack into the correct position in the computer. Connect the HDD pack to
the computer, holding the HDD pack by its sides.
4. Insert the HDD pack.
5. Secure the HDD cover by tightening the HDD cover screw.
