Error! Style not defined. Error! Style not defined. 4 Replacement Procedures
Qosmio X300 Maintenance Manual 4-13
4.4 Memory
Removing the Optional Memory
Remove the optional memory (module) according to the following procedures and Figure 4-4
after checking that the computer is turned off in boot mode.
CAUTION: Remove the optional memory after turning off the computer. If this is violated,
the computer or memory can be damaged.
1. Turn the computer upside down.
2. Release the screw that secures the optional memory cover.
3. Remove the memory cover.
CAUTION: Do not touch the connectors on the memory modules or in the computer.
Contaminated connectors can cause memory access problems.
To Next Page
