Functions of various parts
The various parts of the sewing machine have the functions described below.
2
1
3
Up
Down
Upper thread tension dial
Turn this dial to increase or decrease the
tension of the upper thread.
Reverse sewing button
• When a straight stitch is selected, the
machine will sew in reverse while the
reverse sewing button is pressed.
The machine will sew in reverse
when the reverse sewing button is
pressed without pressing the start/
stop button.
• If a stitch other than a straight stitch
is selected, three reinforcement
stitches are sewn, and then the
machine stops.
Presser foot lever
• When sewing, lower the presser foot lever to
lower the presser foot. (1)
• When inserting fabric, lift up the presser foot
lever to raise the presser foot. (2)
• The presser foot can be raised even higher by
raising the presser foot lever to 3.
* Since the presser foot lever does not remain in 3,
hold it in place while inserting the fabric. This
position is useful when sewing thick fabric.
Handwheel
Turn the handwheel to
manually raise and lower the
needle.
Note
• Always turn the
handwheel towards
yourself (in the direction
of the arrow).
If it is turned in the
opposite direction, the
thread may become
tangled.
With the drop feed lever
at the back of the
machine, the feed dog
can be lowered or raised.
Drop feed lever
