MAINTENANCE AND ADJUSTMENT
103
Cooling System
To ensure efficient engine cooling, check
the coolant level each day before riding
the motorcycle, and top off the coolant
if the level is low.
Note
A year round, Hybrid Organic Acid
Technology (known as Hybrid OAT or
HOAT) coolant is installed in the cooling
system when the motorcycle leaves the
factory. It is colored green, contains a
50% solution of ethylene glycol based
antifreeze, and has a freezing point of
-31°F (-35°C).
Corrosion Inhibitors
Warning
HD4X Hybrid OAT coolant contains
corrosion inhibitors and antifreeze
suitable for aluminum engines and
radiators. Always use the coolant in
accordance with the instructions of
the manufacturer.
Coolant contains toxic chemicals that
are harmful to the human body.
Contact with skin or eyes may cause
severe irritation. Wear protective
gloves, clothing and eye protection
when handling coolant.
If coolant is inhaled, remove the
person to fresh air and keep
comfortable for breathing. In case of
doubt or persistent symptoms, seek
medical attention.
If coolant gets on your skin, flush
with water immediately. Remove
contaminated clothing.
If coolant gets in your eyes, flush with
water for at least 15 minutes and SEEK
MEDICAL ATTENTION IMMEDIATELY.
If coolant is swallowed, rinse the
mouth with water and SEEK MEDICAL
ATTENTION IMMEDIATELY.
KEEP COOLANT OUT OF THE REACH OF
CHILDREN.
Note
HD4X Hybrid OAT coolant, as supplied by
Triumph, is premixed and does not need
to be diluted prior to filling or topping
off the cooling system.
To protect the cooling system from
corrosion, the use of corrosion inhibitor
chemicals in the coolant is essential.

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
