Triumph Speed Twin 900 User Manual

GENERAL INFORMATION
37
Engine Immobilizer / Alarm Indicator
Light
This Triumph motorcycle is
equipped with an engine
immobilizer which is activated
when the ignition switch is
turned to the OFF position.
Not Equipped With Alarm
When the ignition switch is turned
to the OFF position, the engine
immobilizer/alarm light will flash on and
off for 24 hours to show that the engine
immobilizer is on. When the ignition
switch is turned to the ON position the
engine immobilizer and the indicator
light will be off.
If the indicator light remains on it
indicates that the engine immobilizer
has a malfunction that requires
investigation. Contact an authorized
Triumph dealer as soon as possible to
have the fault checked and rectified.
Equipped With Alarm
The engine immobilizer/alarm light will
only illuminate when the conditions
described in the genuine Triumph
accessory alarm instructions are met.
Anti-lock Braking System (ABS)
Warning Light
Warning
If the ABS is not functioning, the brake
system will continue to function as a
non-ABS equipped brake system.
Do not continue to ride for longer than
is necessary with the warning light
illuminated.
Contact an authorized Triumph dealer
as soon as possible to have the fault
checked and rectified. In this situation
braking too hard will cause the wheels
to lock resulting in loss of motorcycle
control and an accident.
Note
Traction control will not function if
there is a malfunction with the ABS.
The warning lights for the ABS, traction
control and the MIL will be illuminated.
When the ignition switch is
turned to the ON position, it is
normal that the ABS warning
light will flash on and off. The
light will continue to flash after engine
start-up until the motorcycle first
reaches a speed exceeding 6 mph
(10 km/h) when it will go off.
The warning light will not illuminate
again until the engine is restarted
unless there is a fault, or the ABS is
disabled by the rider (Scrambler 900
only). If the ABS is disabled by the rider
(Scrambler 900 only) then the warning
light will illuminate until the ABS is
enabled again.
If there is a fault with the ABS system
the warning light will be illuminated and
the general warning symbol will flash.

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
