SPECIFICATIONS
176
Scrambler 900
Dimensions, Weights and Performance
A list of model specific dimensions, weights and performance figures is available
from your authorized Triumph dealer, or on the Internet at www. triumph. co. uk.
Payload Scrambler 900
Maximum Payload 492 lb (223 kg)
Engine Scrambler 900
Type Liquid cooled parallel twin, 270° firing angle
Displacement 54.9 cu in (900 cc)
Bore x Stroke 3.33 x 3.15 in (84.6 x 80 mm)
Compression Ratio 11:1
Cylinder Numbering Left to right
Cylinder Sequence 1-2
Firing Order 1-2
Starting System Electric starter
Lubrication Scrambler 900
Lubrication System Wet sump
Engine Oil Capacities:
Dry Fill 1 gallon (3.8 liters)
Oil/Filter Change 0.9 gallon (3.4 liters)
Oil Change Only 0.85 gallon (3.2 liters)
Cooling Scrambler 900
Coolant Type Triumph HD4X Hybrid OAT
Water/Coolant Ratio 50/50 (pre-mixed as supplied by Triumph)
Coolant Capacity 0.4 gallon (1.518 liters)
Thermostat Opens 190°F (88°C) +/- 35°F (2°C)

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
