Triumph Speed Twin 900 User Manual

MAINTENANCE AND ADJUSTMENT
147
License Plate Light
Bonneville T100 (all models),
Bonneville T120 (all models),
Speed Twin 1200 and Thruxton RS
The license plate light unit is a sealed,
maintenance free LED unit. The license
plate light unit must be replaced in the
event of the failure of the license plate
light.
Scrambler 900 and Speed Twin 900
321 4
1. Fastener
2. Lens unit
3. Bulb
4. License plate bracket
To change the license plate light bulb:
▼ Disconnect the battery, negative
black lead first.
▼ Loosen the fastener from the lens
unit.
▼ Remove the lens unit from the
license plate bracket.
▼ Detach the bulb retainer from the
lens unit.
1
2
1. Bulb
2. Bulb retainer
▼ Carefully remove the bulb from the
bulb retainer. Mount a new bulb into
the bulb retainer.
▼ Remount the bulb retainer into the
lens unit.
▼ Remount the lens unit to the license
plate bracket.
▼ Tighten the fastener to 9 lbf in
(1 Nm).
▼ Reconnect the battery, positive (red)
lead first and tighten the battery
terminals to 40 lbf in (4.5 Nm).
▼ Apply a light coat of grease to the
terminals to prevent corrosion.
▼ Cover the positive terminal with the
protective cap.

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
