Triumph Speed Twin 900 User Manual

CLEANING AND STORAGE
152
After Washing
Warning
Never wax or lubricate the brake discs.
Always clean the brake disc with a
proprietary brand of oil-free brake disc
cleaner.
Waxed or lubricated brake discs may
cause loss of braking power and an
accident.
After washing the motorcycle, do the
following:
▼ Remove the plastic bags and tape,
and clear the air intakes.
▼ Lubricate the pivots, bolts and nuts.
▼ Test the brakes before motorcycle
operation.
▼ Use a dry cloth or chamois leather
to absorb water residue. Do
not allow water to stand on the
motorcycle as this will lead to
corrosion.
▼ Start the engine and run it for
5 minutes. Make sure that there is
adequate ventilation for the exhaust
fumes.
Gloss Paintwork Care
Gloss paintwork should be washed
and dried as described previously,
then protected using a high quality
automotive polish. Always follow the
manufacturer’s instructions and repeat
regularly to maintain your motorcycle’s
appearance.
Matt Paintwork Care
Matt paintwork requires no greater care
than that already recommended for
gloss paintwork.
▼ Do not use any polish or wax on
matt paintwork.
▼ Do not try and polish out scratches.
Aluminum Items - not
Lacquered or Painted
Items such as brake and clutch levers,
wheels, engine covers, engine cooling
fins, upper and lower yokes and
throttle bodies on some models must
be correctly cleaned to preserve their
appearance. Please contact your dealer
if you are unsure which components on
your motorcycle are aluminum parts not
protected by paint or lacquer, and for
guidance on how to clean those items.
Use a proprietary brand of aluminum
cleaner which does not contain abrasive
or caustic elements.
Clean aluminum items regularly, in
particular after use in inclement
weather, where the components must
be hand washed and dried each time
the machine is used.
Warranty claims due to inadequate
maintenance will not be allowed.

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
