Triumph Speed Twin 900 User Manual

GENERAL INFORMATION
70
Helmet Hook (if fitted)
Warning
Never ride the motorcycle with
helmet(s) secured to the helmet hook
as this may cause the motorcycle to
become unstable leading to loss of
control and an accident.
Caution
Do not allow helmet(s) to rest against
a hot muffler. The helmet may be
damaged.
A helmet can be secured to the
motorcycle using the helmet hook
located on the left hand side of the
motorcycle, beneath the seat.
To attach a helmet to the motorcycle:
▼ Remove the seat (see page 71) and
loop the helmet chin strap over the
hook.
▼ Make sure the flat area above
the hook is not obstructed by the
helmet strap, as this will prevent the
seat engaging correctly.
▼ To secure the helmet, re-install the
seat and lock into position.
Seats
Seat Care
Caution
To prevent damage to the seats or
seat covers, care must be taken not to
drop the seats.
Do not lean the seats against the
motorcycle or any surface which may
damage the seats or seat covers.
Instead, place the seats, with the seat
cover facing upwards, on a clean, flat
surface which is covered with a soft
cloth.
Do not place any item on the seats
which may cause damage or staining
to the seat covers.
Thruxton RS Only
Seat Stand
To prevent damage to the seat after
removing:
▼ Release the metal stand from the
underside of the seat.

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
