GENERAL INFORMATION
59
SCROLL Button
The SCROLL button is used to
operate the following functions of the
instruments:
▼ Odometer functions (see page 43)
▼ Trip reset (see page 43)
▼ Clock reset (see page 44)
▼ Traction control functions (see
page 50).
Daytime Running Lights (DRL)
Switch (if equipped)
Note
Daytime running lights are manually
operated. They are not automatic.
The daytime running lights or dip
beam can be selected with the Daytime
Running Lights (DRL) switch.
To select daytime running lights, push
the DRL switch forward.
To select dip beam, push the DRL switch
rearwards.
When the daytime running lights are
turned on, the daytime running lights
indicator light will illuminate in the
instrument panel.
Turn Signal Switch
When the turn signal switch is pushed
to the left or right, the corresponding
turn signals will flash on and off.
The indicators can be canceled
manually. To manually turn off the
indicators, press and release the
indicator switch in the central position.
Horn Button
When the horn button is pushed, with
the ignition switch turned on, the horn
will sound.
Cruise Control Button (if equipped)
When the cruise control button is
pressed, the cruise control is on. Cruise
control remains on until the button
is pressed again to turn off the cruise
control. Cruise control can be switched
on or off at any time but it cannot be
activated until certain conditions have
been met. For more information, see
page 49.
MODE Button
The MODE button allows throttle
response adjustment. Press and release
the MODE button to select one of the
different rider modes available (see
page 45 for more information).
High Beam Light
When the high beam button is
pressed the high beam will be
switched on. Each press of
the button will swap between
dip and high beam.
If daytime running lights are installed on
the motorcycle, the high beam button
has additional functionality.
If the DRL switch is in the daytime
running lights position, then press and
hold the high beam button to turn the
high beam on. It will remain on as long
as the button is held in and will turn off
as soon as the button is released.
A lighting on/off switch is not installed
on this model. The tail light and license
plate light all function automatically
when the ignition is on.
The headlight will function when the
ignition is on. The headlight will go off
while pressing the starter button until
the engine starts.

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
