Triumph Speed Twin 900 User Manual

GENERAL INFORMATION
69
Right Hand Side Panel
The right hand side panel can be
removed to gain access to the rear
brake fluid reservoir.
1
3
4
2
1. Side panel (right hand shown)
2. Upper grommets
3. Lower grommets
4. Side panel attached to lower grommet
To remove the right hand side panel:
▼ Grasp the panel firmly at the top
and pull the panel away from the
motorcycle until it is free from the
two top retaining grommets, leaving
the grommets in place.
▼ Lift up the panel to detach it from
the lower grommet.
To reinstall the right hand side panel:
▼ Position the side panel on to the
lower grommet.
▼ Make sure that the slot in the panel
is fully engaged with the lower
grommet.
▼ Position the two locating dowels to
the upper grommets, then press
firmly to secure the panel.
▼ Finally, grasp the panel and make
sure that it is fully retained.
Tool Kit and Owner’s
Handbook
Tool Kit
The tool kit consists of an adjustment
tool for all models, and additional
C-spanners for Thruxton RS.
Bonneville T100 (all models),
Bonneville T120 (all models),
Speed Twin (all models) and Thruxton RS
The adjustment tool is attached to the
inside of the right hand side panel.
Scrambler 900
The adjustment tool is attached to the
inside of the left hand side panel.
Thruxton RS
There are two C-spanners located under
the seat.
Owner’s Handbook
Bonneville T100 (all models),
Bonneville T120 (all models) and
Thruxton RS
The Owner’s Handbook is located under
the seat on the rear fender.
Scrambler 900 and Speed Twin 1200
The Owner’s Handbook is supplied
separately.
Speed Twin 900
The Owner’s Handbook is located on the
underside of the seat.

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
