Triumph Speed Twin 900 User Manual

GENERAL INFORMATION
65
Fuel Tank Cap
1
1. Fuel tank cap
To open the fuel tank cap:
▼ Remove the cap cover or lift up the
cap flap.
▼ Insert the key into the lock and turn
the key counterclockwise.
▼ Rotate the cap counterclockwise
and lift clear of the tank filler neck.
To close and lock the fuel tank cap:
▼ Align the cap to the tank filler neck
and rotate the cap clockwise until
the cap seals against the filler neck.
▼ In the fully closed position, a ratchet
mechanism prevents overtightening
of the cap by allowing the outer part
of the cap to turn independently of
the internal part.
▼ Turn the key clockwise to lock and
withdraw the key.
▼ Replace the cap cover or securely
close the cap flap.
Filling the Fuel Tank
Warning
Overfilling the tank can lead to fuel
spillage.
If fuel is spilled, thoroughly clean up
the spillage immediately and dispose of
the materials used safely.
Take care not to spill any fuel on the
engine, exhaust pipes, tires or any
other part of the motorcycle.
Because fuel is highly flammable, any
fuel leak or spillage, or any failure to
observe the safety advice given above
may lead to a fire hazard, which could
cause damage to property and injury
or death to persons.
Fuel spilled near to, or onto the tires
will reduce the tires’ ability to grip the
road. This will result in a dangerous
riding condition potentially causing
loss of motorcycle control and an
accident.
Caution
Avoid filling the tank in rainy or dusty
conditions where airborne material can
contaminate the fuel.
Contaminated fuel may cause damage
to fuel system components.

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
