Triumph Speed Twin 900 User Manual

WARRANTY
168
To obtain reimbursement from Triumph
Motorcycles America Limited for such
emergency repairs, you must keep
all failed parts and original receipts,
marked "paid," so you can present them
to an authorized Triumph dealer for
their inspection. Triumph Motorcycles
America Limited recommends that you
bring your motorcycle to an authorized
dealer for inspection to ensure that the
emergency repairs were done properly.
What is Covered by this
Emission Warranty
The emission control system warranty
covers the following "warranted parts"
only:
▼ Fuel injection/engine management
equipment including oxygen sensors
▼ Intake manifold
▼ Air cleaner box
▼ Spark advance/retard system
▼ Spark plugs (first 10,000 miles)
▼ Ignition coils
▼ Charcoal canister
▼ Cap, fuel tank
▼ Fuel/vapor separator (fuel tank)
▼ Vapor valve
▼ Rollover/pressure control valves
▼ If used on the above systems: hoses,
clamps, fittings, tubing, sealing
gaskets and mounting hardware.

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
