GENERAL INFORMATION
47
Selecting a Riding Mode – with the
Motorcycle Stationary
Press and release the MODE button on
either the left or right hand handlebar
switch housing (model specific) until the
required riding mode is flashing in the
display.
The selected riding mode is
automatically activated one second
after the MODE button is pressed, if the
following conditions are met:
With the Engine Off
▼ The ignition is switched ON.
▼ The engine stop switch is in the
RUN position.
With the Engine Running
▼ The transmission is in neutral or the
clutch is pulled in.
Selecting a Riding Mode – when
Riding the Motorcycle
Warning
The selection of riding modes while the
motorcycle is in motion requires the
rider to allow the motorcycle to coast
(motorcycle moving, engine running,
throttle closed, clutch lever pulled
in and no brakes applied) for a brief
period of time.
Riding mode selection while the
motorcycle is in motion should only be
attempted:
- At low speed
- In traffic free areas
- On straight and level roads or
surfaces
- In good road and weather conditions
- Where it is safe to allow the
motorcycle to briefly coast.
Riding mode selection while the
motorcycle is in motion MUST NOT be
attempted:
- At high speeds
- While riding in traffic
- During cornering or on winding roads
or surfaces
- On steeply inclined roads or surfaces
- In poor road/weather conditions
- Where it is unsafe to allow the
motorcycle to coast.
Failure to observe this important
warning will lead to loss of motorcycle
control and an accident.

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
