Triumph Speed Twin 900 User Manual

GENERAL INFORMATION
44
To switch between trip meters, press
and release the SCROLL button, located
on the left hand handlebar switch
housing, until the required trip meter is
shown.
1
1. SCROLL button
Scrambler 900 Only
The trip meters are not accessible when
in OFF ROAD mode. The trip meter data
continues to be collected when riding in
OFF ROAD mode. The updated trip meter
data is shown in the trip meters after
switching the OFF ROAD mode off.
Trip Meter Reset
To reset either of the trip meters:
▼ Select the trip meter to be zeroed.
▼ Press and hold the SCROLL button
for one second. After more than one
second, the trip meter on display will
reset to zero.
Clock
To access the clock, press and release
the SCROLL button, located on the left
hand handlebar switch housing, until
the clock is shown.
1
1. Clock
Clock Adjustment
Warning
Do not attempt to adjust the clock
with the motorcycle in motion as this
may lead to loss of motorcycle control
and an accident.
To reset the clock:
▼ Select the clock display.
▼ Press and hold the SCROLL button
for one second, the clock’s hour
display will start to flash. Release
the SCROLL button.
To reset the hour display:
▼ Make sure the hour display is still
flashing then press and release
the SCROLL button to change the
setting. Each individual button press
will change the setting by one digit.

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
