Triumph Speed Twin 900 User Manual

MAINTENANCE AND ADJUSTMENT
106
Coolant Change
It is recommended that the coolant
is changed by an authorized Triumph
dealer in accordance with scheduled
maintenance requirements.
Radiator and Hoses
Warning
The fan operates automatically when
the engine is running.
Always keep hands and clothing away
from the fan.
Contact with the rotating fan may cause
an accident and/or personal injury.
Caution
Using high pressure water sprays,
such as from a car wash facility or
household pressure washer, can
damage the radiator fins, cause leaks
and impair the radiator's efficiency.
Do not obstruct or deflect airflow
through the radiator by installing
unauthorized accessories, either in
front of the radiator or behind the
cooling fan.
Interference with the radiator airflow
can cause overheating, potentially
resulting in engine damage.
Check the radiator hoses for cracks
or deterioration, and tension clips for
tightness in accordance with scheduled
maintenance requirements. Have your
authorized Triumph dealer replace any
defective items.
Check the radiator grille and fins for
obstructions by insects, leaves or
mud. Clean off any obstructions with a
stream of low pressure water.
Throttle Control
Warning
Always be alert for changes in the
'feel' of the throttle control and have
the throttle system checked by an
authorized Triumph dealer if any
changes are detected.
Changes can be due to wear in the
mechanism, which could lead to a
sticking throttle control.
A sticking or stuck throttle control will
lead to loss of motorcycle control and
an accident.
Throttle Inspection
Warning
Use of the motorcycle with a sticking
or damaged throttle control will
interfere with the throttle function
resulting in loss of motorcycle control
and an accident.
To avoid continued use of a sticking or
damaged throttle control, always have
it checked by your authorized Triumph
dealer.

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
