HOW TO RIDE THE MOTORCYCLE
85
ABS Warning Light
When the ignition switch is
turned to the ON position, it is
normal that the ABS warning
light will flash on and off. The
light will continue to flash after engine
start-up until the motorcycle first
reaches a speed exceeding 6 mph
(10 km/h) when it will go off.
The warning light will not illuminate
again until the engine is restarted unless
there is a fault, or the ABS is disabled by
the rider (Scrambler 900 only).
If the ABS is disabled by the rider
(Scrambler 900 only) then the warning
light will illuminate until the ABS is
enabled again.
If there is a fault with the ABS system
the warning light will be illuminated and
the general warning symbol will flash.
Warning
The ABS warning light will illuminate
when the rear wheel is driven at high
speed for more than 30 seconds when
the motorcycle is on a stand. This
reaction is normal.
When the ignition is switched off
and the motorcycle is restarted, the
warning light will illuminate until the
motorcycle reaches a speed exceeding
19 mph (30 km/h).
Warning
ABS operates by comparing the relative
speed of the front and rear wheels.
Use of non-recommended tires can
affect wheel speed and cause the ABS
not to operate, potentially leading
to loss of control and an accident
in conditions where the ABS would
normally function.
Parking
Warning
Do not park on a soft or steeply
inclined surface.
Parking under these conditions may
cause the motorcycle to fall over
causing damage to property and
personal injury.
Warning
Gasoline is extremely flammable
and can be explosive under certain
conditions.
If parking inside a garage or other
structure, be sure it is well ventilated
and the motorcycle is not close to
any source of flame or sparks. This
includes any appliance with a pilot
light.
Failure to follow the above advice may
cause a fire resulting in damage to
property or personal injury.

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
