Triumph Speed Twin 900 User Manual

MAINTENANCE AND ADJUSTMENT
113
Brakes
Warning
Brake pads must always be replaced
as a wheel set. At the front, where
two calipers are installed on the same
wheel, replace all the brake pads in
both calipers.
Replacing individual pads will reduce
braking efficiency and may cause an
accident.
After replacement brake pads have
been installed, ride with extreme
caution until the new pads have
'broken in'.
Brake pads must be inspected
in accordance with scheduled
maintenance requirements and replaced
if worn to, or beyond the minimum
service thickness.
1
2
1. Brake pads
2. Minimum thickness line
Bonneville T100 (all models) and
Bonneville T120 (all models)
If the lining thickness of any brake
pad (front or rear brakes) is less than
0.06 in (1.5 mm), that is, if the brake pad
has worn down to the bottom of the
grooves, replace all the brake pads on
that wheel.
Scrambler 900, Speed Twin (all models)
and Thruxton RS
If the lining thickness of any brake pad
is less than 0.04 in (1.0 mm) (front) or
0.06 in (1.5 mm) (rear), replace all the
brake pads on that wheel.
Note
Scrambler 900 and Speed Twin (all models)
only
An area of the front brake backing
plate is raised and will cause the front
brake to squeal as notification to the
rider when the brake pad(s) are below
the minimum thickness. Replace all the
brake pads on that wheel.
Breaking-in New Brake Pads and
Discs
Warning
Brake pads must always be replaced
as a wheel set. At the front, where
two calipers are installed on the same
wheel, replace all the brake pads in
both calipers.
Replacing individual pads will reduce
braking efficiency and may cause an
accident.
After replacement brake pads have
been installed, ride with extreme
caution until the new pads have
'broken in'.

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
