Triumph Speed Twin 900 User Manual

WARNING LABEL LOCATIONS
15
Warning Label Locations (continued)
Caution
All warning labels and decals, with the exception of the Breaking-in label, are
mounted on the motorcycle using a strong adhesive. In some cases, labels are
installed prior to an application of paint lacquer. Therefore, any attempt to remove
the warning labels will cause damage to the paintwork or bodywork.
12
76
RON/ROZ 95 min. 91
E5 E10
3900691
Unleaded fuel only
Carb urant sans pl omb
Gaso li na sin pl omo
Bleifreies Benzin
End ast bl yfri bensi n
Benzin a se nza pi ombo
Ongelode Brandstof
Combust ival sem sc humb o
4
5
3
8
1. Engine Oil (page 99)
2. E5 and E10 Fuel (if equipped) (page 63)
3. Unleaded Fuel (page 63)
4. Mirrors (page 121)
5. Windshield (if equipped) (page 155)
6. Tire Pressure Monitoring System
(if equipped) (page 52)
7. Drive Chain (page 109)
8. Tires (Speed Twin 1200 only) (page 131)

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
