Printing
5-5
5
Banner printing
When a document length from 470.1 mm (18.51") to a maximum of 1220.0 mm (48") is specified for printing,
the print job is treated as banner printing.
* When the banner tray (option) is used, up to 10 sheets of banner paper can be fed continuously .
(Refer to Using the Banner Tray (Option) on 5-7.)
Follow the steps below to set banner paper in the printer driver.
1 Click the Basic tab and then click the Page Sizes
button.
2 Click the New button, enter the name, length
(470.1 mm or longer), and width of the custom
paper size being registered, and click the OK
button.
3 Click Print size, select the custom paper size that
you registered, and click the OK button.
NOTE: When KPDL is used for PDL Settings of the printer driver, a length setting of 470.5 mm (18.53") or
longer is handled as banner print.
Max. number of sheets 1 sheet (manual feed), 10 sheets (when optional banner tray is attached*)
Paper width 210 (8.26") to 304.8 (12") mm
Paper length Max. 1220 (48") mm
Paper weight 136 to 163 g/m
2
Paper type Heavy 2
To Next Page
