Preparation before Use
2-5
2
Connecting Cables
Connecting LAN Cable (Optional)
Follow the steps below to connect a LAN cable to the machine.
1 When the machine is powered up, first press the
Power key on the operation panel. Check that the
Power indicator, the processing indicator and the
memory indicator are off. After this, turn off the
main power switch.
2 Connect the LAN cable to the network interface
connector located on left side of the body.
3 Connect the other end of the cable to the hub.
4 Power on the machine, and configure the network.
For details, refer to Network Setup (LAN Cable
Connection) on page 2-13.
To Next Page
